Product Name | Angle Steel |
Length | As required |
Width | Equal and unequal angles can be customized according to customer needs |
Standard | AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc. |
Technique | Hot rolled / cold rolled |
Surface Treatment | 2B or according to customer requirement |
Thickness tolerance | ±0.01mm |
Material | A36 Q235/Q235B/Q345/Q345B/ S235JR/S235/S355JR/S355/ST37-2/ST52-3/ SS400/SM400A/SM400B/SS490/SM490/SS540 stainless: 200/300/400 series |
Application | It is widely used in high temperature applications, medical devices, building materials, chemistry, food industry, agriculture, ship components.It also applies to food, beverage packaging, kitchen supplies, trains, aircraft, conveyor belts, vehicles, bolts, nuts, springs, and screen. |
MOQ | 1tons.We also can accept sample order. |
Shipment time | Within 15-20 workdays after receiving deposit or L/C |
Export packing | Waterproof paper, and steel strip packed.Standard Export Seaworthy Package.Suit for all kinds of transport,or as required |
Capacity | 250,000 tons/year |
Name | angle bar | |
Standard | AISI, ASTM, BS, DIN, GB, JIS, etc | |
Material | A36 Q235/Q235B/Q345/Q345B/ S235JR/S235/S355JR/S355/ST37-2/ST52-3/ SS400/SM400A/SM400B/SS490/SM490/SS540 stainless: 200/300/400 series | |
Thickness | 3-24mm | |
Equal Angle | Type: | 2#-20# |
Size: | 20-200mm | |
Thickness: | 3.0-24mm | |
Weight: | 0.597-71.168kg/m | |
Unequal Angle | Type: | 2.5*1.6-20*12.5# |
Size: | 25*16-200*125mm | |
Long Side: | 20-200mm | |
Short Side: | 16-125mm | |
Thickness: | 3.0-24mm | |
Weight: | 1.687-43.588kg/m | |
Length | 1-12m or as customer request | |
Surface | Black,Bright,Rough Turned,Polishing,Blasting,Grinding,Centreless ground,Pickled,etc | |
Technique | Hot Rolled,Cold Rolled,Cold Drawn,Forged | |
Package | By bundles with steel strips or according to the requirements of customers |
Unequal Angle Steel Sizes | |||||
Size | Theoretical weight | SIZE | Theoretical weight | SIZE | Theoretical weight |
125*75*7 | 10.700 | 100*80*10 | 13.476 | 180*110*16 | 34.649 |
125*75*8 | 12.200 | 110*70*6 | 8.350 | 200*125*12 | 29.761 |
125*75*9 | 13.600 | 110*70*7 | 9.656 | 200*125*14 | 34.436 |
125*75*10 | 15.000 | 110*70*8 | 10.946 | 200*125*16 | 39.045 |
125*75*12 | 17.800 | 110*70*10 | 13.476 | 200*125*18 | 43.588 |
45*30*4 | 2.251 | 125*80*7 | 11.066 | 200*125*20 | 47.885 |
50*32*4 | 2.494 | 125*80*8 | 12.551 | 100*75*6 | 8.060 |
56*36*4 | 2.818 | 125*80*10 | 15.474 | 100*75*7 | 9.340 |
63*40*5 | 3.466 | 125*80*12 | 18.330 | 100*75*8 | 10.600 |
63*40*6 | 3.920 | 140*90*8 | 14.160 | 100*75*9 | 11.800 |
75*50*5 | 4.638 | 140*90*10 | 17.475 | 100*75*10 | 13.000 |
75*50*6 | 4.808 | 140*90*12 | 20.724 | 100*75*12 | 15.350 |
75*50*8 | 5.699 | 140*90*14 | 23.908 | 150*90*8 | 14.700 |
90*56*6 | 7.431 | 160*100*10 | 19.872 | 150*90*9 | 16.400 |
90*56*8 | 6.717 | 160*100*12 | 23.592 | 150*90*10 | 18.200 |
100*63*6 | 8.779 | 160*100*14 | 27.035 | 150*90*12 | 21.600 |
100*63*8 | 7.550 | 160*100*16 | 30.835 | 200*100*10 | 23.000 |
100*63*10 | 9.878 | 180*110*10 | 22.273 | 200*100*12 | 27.620 |
100*80*6 | 12.142 | 180*110*12 | 26.464 | 200*100*15 | 30.040 |
100*80*8 | 10.946 | 180*110*14 | 30.589 |
![]() | ![]() |
![]() | ![]() |
